Case Study: Conveyor Equipment Manufacturer Turns a Hand-Bent Part Into a Repeatable Production Component

A conveyor systems and material handling equipment manufacturer needed a better way to source one of its custom wire form components. The part had been bent by hand in-house, which made consistency difficult and limited their ability to scale production with confidence.

After finding Ace Wire Spring & Form Co. through an online search, the customer reached out for help producing the wire form as a professionally manufactured component. What began as a single custom wire form inquiry grew into an ongoing supplier relationship that now includes multiple wire forms and springs used across the customer’s conveyor equipment.

The Challenge: In-House Hand Forming Was Not Consistent or Scalable

The customer originally produced the wire form manually in-house. While this may have worked in the early stages, hand forming created challenges that became harder to ignore over time.

Their team needed a part that was:

• Consistent from piece to piece
• Repeatable in production
• Better suited for ongoing volume needs
• Supported by clear documentation and a professional manufacturing process

Without a formal production drawing and repeatable manufacturing method, maintaining uniformity could be difficult. As their equipment needs continued, they wanted a supplier who could take a hand-made component and turn it into a production-ready product.

The Solution: Reverse Engineering, Design Support, and a Structured Approval Process

Online Discovery and Initial Inquiry

While searching online for a supplier to produce a bent wire component, the manufacturer found Ace Wire Spring. They submitted a custom wire form request, provided a sample and CAD reference, and outlined expected ongoing quantities.

This gave Ace a starting point for evaluating the application and determining the best path toward full production.

Engineering Review and Reverse Engineering

Ace’s engineering team reviewed the part and reverse-engineered it into a production-ready drawing. This step helped convert the customer’s concept and sample into a documented component that could be manufactured consistently.

As needed, Ace also provided design assistance and manufacturability recommendations based on experience. The goal was not only to match the original form, but to help ensure it could be produced efficiently and reliably in an ongoing manufacturing environment.

Quoting, Samples, and Approval Drawing Sign-Off

Once the part was reviewed, Ace quoted the wire form and supported the customer’s approval drawing sign-off requirement before fabrication moved forward.

Ace coordinated the samples so the customer could review fit and function before committing to a full production run. This approval stage gave the customer confidence that the final part would perform as expected in its conveyor equipment.

Prototype Approval Before Production

Ace manufactured prototype samples for evaluation, and the customer approved them before production began.

With the approved drawing and sample validation complete, the customer issued its first purchase order and moved ahead with production.

The Results: From One Wire Form to an Ongoing Multi-Part Supplier Relationship

A Repeatable, Professionally Manufactured Wire Form

The first major result was the successful transition from a hand-bent in-house part to a professionally produced wire form supported by an approved production drawing.

This improved consistency and gave the customer a repeatable part they could rely on for ongoing equipment builds.

Expansion Into Additional Wire Forms

After the initial order was successful, the relationship continued to grow. The customer sent additional wire form parts to Ace for quoting and production, expanding the scope of the partnership beyond the original component.

This is often a strong sign that a supplier has earned trust not just on price, but also on quality, communication, and reliability.

Growth Into Spring Production

Over time, the customer also began sourcing springs from Ace in addition to wire forms. What started as a single-part inquiry developed into a broader manufacturing relationship supporting multiple component types across the customer’s conveyor systems.

An Ongoing Supply Partnership

Today, Ace supports this customer as a repeat supplier for multiple wire forms and springs used in their conveyor equipment. The relationship reflects the value of combining engineering support, a clear approval process, and dependable production for custom components.

A Reliable Manufacturing Partner for Custom Wire Forms and Springs

For this conveyor systems and material handling equipment manufacturer, the need was straightforward. They wanted to replace a hand-made wire form with a part that was consistent, repeatable, and professionally produced.

By working with Ace Wire Spring & Form Co., they were able to move from an in-house-formed component to an approved production part, then expand the relationship to include additional wire forms and springs.

Ace continues to support OEMs and equipment manufacturers with custom wire forms, springs, and engineering-backed production solutions that help simplify sourcing and improve repeatability.

Looking for a dependable supplier for custom wire forms or springs? Contact Ace Wire Spring & Form Co. to discuss your application.
